Mountain bikes are just that, a bike to take to off road into the mountains. These bikes typically have suspension forks and/or rear suspension. KHS makes Mountain bikes that give you a comfortable fit to help you be able to get and ride all day long.
| Size | Small/51 | Medium/53 | Medium/Large/56 | Large/58 |
|---|---|---|---|---|
| s/t c-t | 490/19.3 | 520/20.5 | 560/22 | 580/22.8 |
| h/t° | 70.5° | 71° | 72° | 72° |
| s/t° | 74.5° | 74° | 73° | 73° |
| t/t effectv | 520/20.5 | 535/21.1 | 565/22.2 | 580/22.8 |
| c/s | 435/17.1 | 435/17.1 | 435/17.1 | 435/17.1 |
| BB Height | 283/11.1 | 283/11.1 | 283/11.1 | 283/11.1 |
| s.o. | 759/29.9 | 786/31 | 823/32.4 | 841/33.1 |
| h/t L | 120/4.7 | 140/5.5 | 170/6.7 | 190/7.5 |
| Stack | 537/21.1 | 557/21.9 | 589/23.2 | 608/23.9 |
| Reach | 371/14.6 | 375/14.8 | 385/15.1 | 394/15.5 |
Specs
| Frame | 4-Bar Horst Link 29/650B+ 130mm, 6061 Aluminum w/Custom Formed Double Butted T/T & D/T, 1.5 Taper, 12 x 148 Rear Axle, w/Replaceable Derailleur Hanger, Internal Cable |
|---|---|
| Fork | SR XCR34 Boost, LOR Air, S:27.5, M-XL:29”, 140mm, 34mm Stanchions, Aluminum Steerer, Magnesium Lowers, Hydraulic Damp, External rebound, Lock-Out, 1.5 Taper, 15QR x 110mm |
| Rear Shock | X-Fusion 02 Pro RL, Air, Ext Rebound, Lock-Out |
| Rims | WTB ST=S:i35, M-XL:i29 TCS, Disc, Double Wall, 32H, Tubeless-Ready |
| Hubs |
Front: Formula Sealed Bearing Aluminum Disc, 15mm, 110mm Boost Rear: Formula Sealed Bearing Aluminum Disc, Cassette, 12 x 148mm Boost |
| Spokes | 14G Stainless Black w/Aluminum Nipples, 32x32 |
| Tires | Kenda Regolith Pro, S:27.5 x 2.6”, M-XL:29 x 2.4”, 120TPI, Folding, Tubeless-Ready |
| Bottom Bracket | SR Outboard Cartridge Bearing |
| Crankset | SR Zeron, 2-pc, Boost, 30T Zig/Zag, S:170, M-XL:175 |
| Shifters | Shimano Deore, SL-M6100, 12s, Trigger, Right Only |
| Rear Derailleur | Shimano Deore, RD-M6100 |
| Cassette/Freewheel | Shimano CS-M6100, 10-51T, 12-Speed |
| Chain | Shimano CN-M6100 |
| Brakes | Shimano MT200 Hydraulic Disc, 180/160mm Rotors Wave 12 |
| Brake Levers | Shimano MT200 |
| Handlebars | Aluminum 35mm Riser, 780 x 15mm |
| Tape/Grips | Q2 Lock-on |
| Stem | 35mm Aluminum 3D Forged, Threadless 4-bolt |
| Headset | FSA Orbit 1.5E, Zero Stack, 1-1/8”~1.5 |
| Seatpost | Kind Shock Exa-Form KSP-900-i, Integra w/Remote, Travel Adjust, 31.6mm |
| Saddle | WTB Volt Medium SL |
| Pedals | Sold separately |
* Subject to change without notice.
