Name: X-Route 100
Price: 699.00 USD
Availability: InStock

$699.00

Details

More and more people are riding bicycles to get where they need to go. Commuter bikes are designed to ride comfortably, efficiently, and reliably. Save gas, get in shape, and save the environment. KHS has created three distinct lines bikes to cater to every commuter’s needs.

Geometry

Geometry Chart:
	X-Small/14	Small/15.5	Medium/18	Large/20.5	X-Large/23
s/t c-t	355/14	394/15.5	457/18	521/20.5	584/23
h/t°	71°	71°	71°	71°	71°
s/t°	73°	73°	73°	73°	73°
t/t effectv	547/21.5	558/22	576/22.7	588/23.1	601/23.7
c/s	450/17.7	450/17.7	450/17.7	450/17.7	450/17.7
BB Height	280/11	280/11	280/11	280/11	280/11
s.o.	695/27.4	722/28.4	763/30	802/31.6	842/33.1
h/t L	95/3.7	110/4.3	130/5.1	145/5.7	165/33.1
Stack	542/21.3	556/21.9	556/21.9	589/23.2	608/23.9
Reach	381/15	388/15.3	388/15.3	407/16	415/16.3

Specs

Frame	6061 Aluminum w/Custom Formed T/T & D/T w/C/S Disc Mount, w/Replaceable Derailleur Hanger
Fork	Full CrMo Unicrown, Low-rider and Fender Bosses w/Disc, Straight Blade
Rims	Weinmann U26 Disc, 700x32H, Double Wall
Hubs	Front: KK Aluminum Disc, QR w/Rubber Seal Rear: KK Aluminum Disc, QR w/Rubber Seal, Cassette
Spokes	14G Stainless Black, 32x32
Tires	Kenda Kwick Bitumen K1068, 700 x 40c
Bottom Bracket	FSA Cartridge Bearing
Crankset	Shimano FC-TY301, 48/38/28T w/Chainguard, XS-M: 170, L-XL: 175
Shifters	Shimano, ST-EF500
Front Derailleur	Shimano, FD-TY710, 34.9mm
Rear Derailleur	Shimano, RD-TY300
Cassette/Freewheel	Shimano, CS-HG20-7, 12-32T, 7-Speed
Chain	KMC Z8.3
Brakes	Bengal Cable Disc, MB606, 160mm, Wave 12 Rotors
Brake Levers	Shimano ST-EF500
Handlebars	Aluminum Trekking, 630mm, 31.8mm
Tape/Grips	Q2 Ergo Lock-On, Dual Density
Stem	KHS Aluminum Threadless, 17D, 4-bolt, XS:80mm, S-L: 90mm, XL: 100mm
Headset	Threadless 1-1/8”, Zero Stack
Seatpost	KHS Aluminum Micro-Adjust, 31.6mm
Saddle	KHS Ultra Comfort Plus, Soft Shell w/Memory Foam
Pedals	Wellgo Platform w/Non-Slip Tread, DU Bearings
